| Place of Origin: | Zhejiang, China |
|---|---|
| Brand Name: | XINSHENG |
| Model Number: | XS-A |
| Minimum Order Quantity: | 1 Piece |
| Price: | $2.95 - $90.50/sets |
| Packaging Details: | Inner box and export carton |
| Supply Ability: | 25000 Set/Sets per Month |
| Application: | General | Port Size: | 1/4" 3/8" 1/2" G / NPT |
|---|---|---|---|
| Material: | Brass | Power: | Solenoid |
| Temperature Of Media: | NBR -5~80℃/ VITON -5~180℃ | Pressure: | 0~20 Bar |
| Structure: | Direct Acting Diaphram | Media: | Water / Hotwater / Gas |
| Standard Or Nonstandard: | Standard | NC Or NO: | Normally Closed |
| Coil Type: | IP65 Coil | Voltage: | AC 220V/110V DC 12V/24V Or Other Can Be Customized. |
| Sealing: | NBR / EPDM / VITON | Port: | NINGBO |
| Model | Port Connect | DN (mm) | Cv | Operating pressure ( Bar) | Max temperature of fluid | Coil | Dimension | |||||||||
| Min | Max pressure | Class | Power | |||||||||||||
| Air mashgas | water. liquid | Light oil ≤20CST | AC220 | DC24 | L x W x H AxBxC (mm) | |||||||||||
| AC | DC | AC | DC | AC | DC | NBR | VITON | VA | W | |||||||
| XS-A-08 | 1/4" | 10 | 1.9 | 0 | 20 | 16 | 20 | 16 | 20 | 16 | 80℃ | 180℃ | F | 22 | 15 | 50x41x108 |
| XS-A-10 | 3/8" | 10 | 2.4 | 0 | 20 | 16 | 20 | 16 | 20 | 16 | 80℃ | 180℃ | F | 22 | 15 | 50x41x108 |
| XS-A-15 | 3/8" | 10 | 2.4 | 0 | 20 | 16 | 20 | 16 | 20 | 16 | 80℃ | 180℃ | F | 22 | 15 | 50x41x108 |
Yuyao Xinsheng Solenoid Valve Co.,Ltd is established in 2005.It is a specialized manufacturer combined with research, development and production of solenoid valve . It has advanced management mechanism and the excellent mechanical processing design and perfect production testing equipment. “Xinsheng” solenoid valve has significant advantages such as reliable performance ,easy control and energy-saving, it is widely used in machinery, chemical industry, light industry, environmental protection, food and other industries, as well as the central air conditioning and wastewater treatment engineering.
Our factory produces all kinds of working medium solenoid valve with diameter Φ3-Φ300 and pressure range 0-1.7 mpa. Main products:Water liquid gas electric solenoid valve, steam solenoid valve, diaphragm solenoid valve, piston type solenoid valve, freon solenoid valve, gas solenoid valve, stainless steel acid and alkaline solenoid valve, air solenoid valve, fountain solenoid valve and etc,more than 100 kinds of specifications.
We will assure you high quality with good management and service , reward our customers with good credit, continuous innovation, develop high quality products and better meet the needs of the customers.The company passed the ISO9001:2000 quality management system certification in 2005 .
For Neutral packing or OEM customized packing, welcome to contact us.
