| Place of Origin: | Zhejiang, China |
|---|---|
| Brand Name: | XINSHENG |
| Model Number: | 2W025-08 |
| Minimum Order Quantity: | 1 Piece |
| Price: | $2.60 - $3.50/sets |
| Packaging Details: | Inner box and export carton |
| Supply Ability: | 50000 Set/Sets per Month |
| Application: | General | Port Size: | 1/4" BSP / NPT |
|---|---|---|---|
| Material: | Brass | Power: | Solenoid |
| Temperature Of Media: | NBR -5~80℃/ VITON -5~180℃ | Pressure: | 0~10 Bar |
| Structure: | Direct Acting | Media: | Water / Hotwater / Gas |
| Standard Or Nonstandard: | Standard | NC Or NO: | Normally Closed |
| Coil Type: | DIN Coil (IP65) Or Round Iron Coil (IP54) | Voltage: | AC 220V/110V DC 12V/24V Or Other Can Be Customized. |
| Sealing: | NBR / EPDM / VITON | Port: | NINGBO |
| Model | Port Connect | Orifice (mm) | Cv | Operating pressure ( Bar) | Max temperature of fluid | Coil | Dimension | |||||||||
| Min | Max pressure | Class | Power | |||||||||||||
| Air mashgas | water. hotwater. liquid | Light oil ≤20CST | AC 220V | DC 24V | L x W x H AxBxC (mm) | |||||||||||
| AC | DC | AC | DC | AC | DC | NBR | VITON | VA | W | |||||||
| 2W025-08A | 1/4" | 2.5 | 0.23 | 0 | 8 | 8 | 8 | 8 | 8 | 8 | 80℃ | 180℃ | B | 25 | 16 | 40x26 x75 |
| 2W025-08 | 1/4" | 2.5 | 0.23 | 0 | 8 | 8 | 8 | 8 | 8 | 8 | 80℃ | 180℃ | B | 25 | 16 | 40x30 x75 |
2W040-10 3/8 inch https://www.alibaba.com/product-detail/2W040-10-3-8-inch-direct_60653234454.html?spm=0.manage.list.4.5c95b8742hzlfU
2W160-10 3/8 inch https://www.alibaba.com/product-detail/2W160-10-3-8-inch-direct_60622182795.html?spm=0.manage.list.34.4e2686cfURfwRu
2W160-15 1/2 inch https://www.alibaba.com/product-detail/2W160-15-1-2-inch-water_60702809087.html?spm=0.manage.list.4.3d2b6539m1tnKH
2W200-20 3/4 inch https://www.alibaba.com/product-detail/2W200-20-3-4-inch-direct_60623575366.html?spm=0.manage.list.7.3d2b6539m1tnKH
2W250-25 1 inch https://www.alibaba.com/product-detail/2W250-25-1-inch-direct-acting_60653745683.html?spm=0.manage.list.31.3d2b6539m1tnKH
2W320-32 1 1/4 inch https://www.alibaba.com/product-detail/2W320-32-11-4-inch-direct_60624191648.html?spm=0.manage.list.16.3d2b6539m1tnKH
2W400-40 1 1/2 inch https://www.alibaba.com/product-detail/2W400-40-1-1-2-inch_60624482260.html?spm=0.manage.list.10.3d2b6539m1tnKH
2W500-50 2 inch https://www.alibaba.com/product-detail/2W500-50-2-inch-direct-acting_60623553537.html?spm=0.manage.list.28.3d2b6539m1tnKH
2W400-40F DN40 FLANGE https://www.alibaba.com/product-detail/2W400-40F-brass-direct-acting-diaphram_60622764305.html?spm=0.manage.list.19.3d2b6539m1tnKH
2W500-50F DN50 FLANGE https://www.alibaba.com/product-detail/2W500-50F-brass-direct-acting-diaphram_60624156905.html?spm=0.manage.list.22.3d2b6539m1tnKH
Yuyao Xinsheng Solenoid Valve Co.,Ltd is established in 2005.It is a specialized manufacturer combined with research, development and production of solenoid valve . It has advanced management mechanism and the excellent mechanical processing design and perfect production testing equipment. “Xinsheng” solenoid valve has significant advantages such as reliable performance ,easy control and energy-saving, it is widely used in machinery, chemical industry, light industry, environmental protection, food and other industries, as well as the central air conditioning and wastewater treatment engineering.
Our factory produces all kinds of working medium solenoid valve with diameter Φ3-Φ300 and pressure range 0-1.7 mpa. Main products:Water liquid gas electric solenoid valve, steam solenoid valve, diaphragm solenoid valve, piston type solenoid valve, freon solenoid valve, gas solenoid valve, stainless steel acid and alkaline solenoid valve, air solenoid valve, fountain solenoid valve and etc,more than 100 kinds of specifications.
We will assure you high quality with good management and service , reward our customers with good credit, continuous innovation, develop high quality products and better meet the needs of the customers.The company passed the ISO9001:2000 quality management system certification in 2005 .
For Neutral packing or OEM customized packing, welcome to contact us.
