| Place of Origin: | Zhejiang, China |
|---|---|
| Brand Name: | XINSHENG |
| Model Number: | 2W400-40SF |
| Minimum Order Quantity: | 1 Piece |
| Price: | $60.00 - $70.00/sets |
| Packaging Details: | Inner box and export carton |
| Supply Ability: | 25000 Set/Sets per Month |
| Application: | General | Port Size: | Flanged DN40 |
|---|---|---|---|
| Material: | Stainless Steel | Power: | Solenoid |
| Temperature Of Media: | NBR -5~80℃/ VITON -5~180℃ | Pressure: | 0~10 Bar |
| Structure: | Direct Acting Diaphram | Media: | Water/hotwater/gas |
| Standard Or Nonstandard: | Standard | NC Or NO: | NC |
| Coil Type:: | Round Iron Coil (IP54) Or DIN Coil (IP65) | Voltage: | AC 220V/110V DC 12V/24V Or Other Can Be Customized. |
| Sealing: | NBR / EPDM / VITON | Port: | NINGBO |
| Model | Port size | DN (mm) | Cv | Operating pressure ( Bar) | Max temperature of fluid | Coil | Dimension | |||||||||
| Min | Max pressure | Class | Power | |||||||||||||
| Air mashgas | water. hotwater. liquid | Light oil ≤20CST | AC220 | DC24 | L x W x H AxBxC (mm) | |||||||||||
| AC | DC | AC | DC | AC | DC | NBR | VITON | VA | W | |||||||
| 2W400-40SF | Flange | 40 | 29 | 0 | 10 | 6 | 10 | 6 | 7 | 4 | 80℃ | 180℃ | B | 35 | 30 | |
2W025-08S 1/4inch : https://www.alibaba.com/product-detail/2W025-08S-1-4-inch-SS304_60623757503.html?spm=0.manage.list.4.1aa5c955pM1qHL
2W200-20S 3/4inch: https://www.alibaba.com/product-detail/2W200-20S-3-4-inch-stainless_60624323374.html?spm=0.manage.list.37.1aa5c955pM1qHL
2W250-25S 1inch:https://www.alibaba.com/product-detail/2W250-25S-1-2-inch-direct_60622985976.html?spm=0.manage.list.34.1aa5c955pM1qHL
2W320-32S 1-1/4 inch:https://www.alibaba.com/product-detail/2W320-32S-1-1-4-inch_60624925012.html?spm=0.manage.list.13.1aa5c955pM1qHL
2W400-40S 1-1/2 inch: https://www.alibaba.com/product-detail/2W400-40S-1-1-2-inch_60624944279.html?spm=0.manage.list.7.1aa5c955pM1qHL
2W500-50S 2 inch:https://www.alibaba.com/product-detail/2W500-50S-2-inch-direct-acting_60624494339.html?spm=0.manage.list.40.1aa5c955pM1qHL
2W160-15SF FLANGE :https://www.alibaba.com/product-detail/2W160-15SF-direct-acting-SS304-Flanged_60654787300.html?spm=0.manage.list.22.1aa5c955pM1qHL
2W200-20SF FLANGE: https://www.alibaba.com/product-detail/2W200-20SF-direct-acting-SS304-Flanged_60654820869.html?spm=0.manage.list.25.1aa5c955pM1qHL
2W250-25SF FLANGE: https://www.alibaba.com/product-detail/2W250-25SF-direct-acting-SS304-Flanged_60625153729.html?spm=0.manage.list.19.1aa5c955pM1qHL
2W320-32SF FLANGE: https://www.alibaba.com/product-detail/2W320-32SF-direct-acting-SS304-Flanged_60625556602.html?spm=0.manage.list.28.1aa5c955pM1qHL
2W500-50SF FLANGE: https://www.alibaba.com/product-detail/2W500-50SF-direct-acting-SS304-Flanged_60624616782.html?spm=0.manage.list.31.1aa5c955pM1qHL
Yuyao Xinsheng Solenoid Valve Co.,Ltd is established in 2005.It is a specialized manufacturer combined with research, development and production of solenoid valve . It has advanced management mechanism and the excellent mechanical processing design and perfect production testing equipment. “Xinsheng” solenoid valve has significant advantages such as reliable performance ,easy control and energy-saving, it is widely used in machinery, chemical industry, light industry, environmental protection, food and other industries, as well as the central air conditioning and wastewater treatment engineering.
Our factory produces all kinds of working medium solenoid valve with diameter Φ3-Φ300 and pressure range 0-1.7 mpa. Main products:Water liquid gas electric solenoid valve, steam solenoid valve, diaphragm solenoid valve, piston type solenoid valve, freon solenoid valve, gas solenoid valve, stainless steel acid and alkaline solenoid valve, air solenoid valve, fountain solenoid valve and etc,more than 100 kinds of specifications.
We will assure you high quality with good management and service , reward our customers with good credit, continuous innovation, develop high quality products and better meet the needs of the customers.The company passed the ISO9001:2000 quality management system certification in 2005 .
For Neutral packing or OEM customized packing, welcome to contact us.
